Neon

10

Ne

20.1797(6)
  • Name: Neon
  • Symbol: Ne
  • Atomic number: 10
  • Atomic weight: 20.1797(6)
  • CAS Registry ID: 7440-01-9
  • Group name: Noble gas
  • Period number: 2
  • Block: p-block
  • Switch:
  • Compare Element

Description

Neon is a noble gas that is present in only minute quantities on Earth. In its natural state, Neon is a colorless gas with an atomic weight of 20.1797, a melting point of - 415.46 °F, and a boiling point of - 410.94 °F. Neon advertising signs is the main use of neon, other uses include: as a liquid for cryogenic refrigeration, combined with helium for use in gas lasers, and in the use of high-voltage indicators, T.V. tubes, and lightning arrestors.

enlarge image

Isolation

The isolation of neon is only produced on an industrial basis. Neon is available for commercial use and so it is not normally isolated in a laboratory setting.

enlarge image

As neon is a very rare gaseous element on Earth that is found only in the air, the only process that is used to isolate neon is through fractional distillation of liquefied air. The process of fractional distillation involves using large industrial distillation columns to capture and heat continuous flows of air. As the air is heated, the liquefied gases are separated out from one another by using the different boiling points of the gases. The final steps of neon isolation involve separating helium and nitrogen from the neon; increased pressure and cooling cause the nitrogen to be removed through condensation. Helium and neon are separated by using low temperature selective adsorption through activated charcoal. The amount of liquid air that is needed to produce one pound of neon is 88,000 pounds. While small scale laboratory isolation using fractional distillation of neon is possible, it is inefficient and a lot of energy is needed in order to produce minute quantities of neon.
General
Name Neon
Symbol Ne
Number 10
Chemical series noble gases
Group 18
Period 2
Block p
Appearance colorless
Standard atomic weight 20.1797(6) g·mol−1
Electron configuration 1s2 2s2 2p6
Electrons per shell 2, 8
Atomic properties
Crystal structure cubic face centered
Oxidation states
Electronegativity
Ionization energies 1st: 2080.7 kJ·mol−1
(more) 2nd: 3952.3 kJ·mol−1
(more) 3rd: 6122 kJ·mol−1
Atomic radius
Atomic radius (calc.) 38 pm
Covalent radius 69 pm
Van der Waals radius 154 pm
Physical properties
Phase gas
Density (near r.t.) (0 °C, 101.325 kPa) 0.9002 g/L
Liquid density at m.p.
Melting point 24.56 K (-248.59 °C, -415.46 °F)
Boiling point 27.07 K (-246.08 °C, -410.94 °F)
Critical point 44.4 K, 2.76 MPa
Heat of fusion 0.335 kJ·mol−1
Heat of vaporization 1.71 kJ·mol−1
Heat capacity (25 °C) 20.786 J·mol−1·K−1
Miscellaneous
Magnetic ordering nonmagnetic
Electrical resistivity
Thermal conductivity (300 K) 49.1 m W·m−1·K−1
Thermal expansion
Speed of sound (thin rod) (gas, 0 °C) 435 m/s
Young's modulus
Shear modulus
Bulk modulus 654654 GPa
Poisson ratio
Mohs hardness
Vickers hardness
Brinell hardness
CAS registry number 7440-01-9
